Elmasonic Xtra 40 Ultrasonic unit, with heating and drain, 220 - 240 V

Product information "Elmasonic Xtra 40 Ultrasonic unit, with heating and drain, 220 - 240 V"

Elmasonic Xtra ultrasonic table-top units are designed for use in production, workshops and service. All functions and cleaning parameters, such as time and heating preselection, can be set and monitored at a glance on the user-friendly front control panel.

The powerful Dynamic mode ensures perfect cleaning results with optimum distribution of the ultrasound in the water bath, even with stubborn dirt. The energy-saving Eco mode is used for lighter soiling.

The LED displays signal the corresponding status to the user, for example when the cleaning process is complete. But safety also plays a major role - the dry-running protection ensures that the appliance switches off automatically if there is too little water in the bath to prevent damage to the bath.

Functions

37 kHz ultrasonic frequency (control range -2.5 / +5.5 kHz)
2 ultrasonic modes

dynamic mode for intensive cleaning with higher cleaning performance
eco mode for gentle cleaning with quieter, more economical operation

Electronic selector switch on wipeable membrane keypad
LED display of all operating statuses
Cleaning duration adjustable between 1 minute and 30 minutes or continuous operation (ultrasonic continuous operation max. 6 hours)
Acoustic and visual signal at the end of cleaning
Temperature control adjustable in steps of 5 °C from 30 to 80 °C (temperature tolerance -5 / +8 °C)
Automatic safety switch-off with wake-up function

after 8 hours of non-use
by briefly interrupting the power supply

Automatic switch-off of ultrasonic operation at a bath temperature > 90 °C
Splash-proof stainless steel housing
Stainless steel liquid drain on the side of the appliance
Sloped tank base for better draining
Dry run detection
Durable stainless steel cleaning tray
2-year warranty from initial commissioning, maximum 3 years from production date

Scope of delivery

Ultrasonic appliance
Stainless steel lid
Mains cable with IEC connection (2 m long)
Operating instructions

Technical data

Consumption: 540 W
Dimensions (H x W x D): 330,0 x 415,0 x 215,0 mm
Drain: 1/2″
Frequency: 37 kHz
Heating: 400 W
Inner dimension (H x W x D): 150 x 235 x 135 mm
Material: Stainless steel
Noiselevel: < 80 dB (LpAU), < 110 dB (LpZ)
Operating capacity: 4 l
Power supply: 220 - 240V
Product area: Equipment & machines
Properties: 2 ultrasound modes, Automatic safety shutdown, Electronic temperature control, Electronic temperature control
Reference: Xtra 40
Series: Xtra
Size: 40
Temperature: 30 - 80 °C
Typ: Ultrasonic device
Weight (kg): 7.76
